Pneumatic Vise VMC-8P

Pneumatic Machine Vise VMC-8P

The VMC-8P vise is a precise, robust vise with a solid construction, ideal for demanding industrial applications. Thanks to its quick and reliable clamping and subsequent release of the workpiece, the VMC-8P is an excellent choice for mass production where short working time is crucial. This vise significantly improves work efficiency by reducing non-productive times associated with part changes.

Key Features:

• Maximum opening: 200 mm
• Jaw width: 200 mm
• Clamping force: 9000 kgf
• Weight: 74 kg
• Switching speed: 1.5 s

Construction and Material:

• The vise is made of high-quality ductile iron, which ensures long life and high resistance to mechanical wear.
• The vise's induction-hardened base and jaws provide excellent strength and protection against wear during intensive use.
• Special movable jaw pressure system: When the vise is tightened, the movable jaw is pressed towards the base, preventing the workpiece from lifting and ensuring stable clamping.

Package contents:

• 2x leveling stones (18 mm) for precise vise setup
• 4x clamps for firm and reliable holding of workpieces
• 1x handle for easy and efficient vise operation

Advantages:

• Possibility to mount multiple vises on the machine table to increase productivity and efficiency in series clamping.
• High clamping speed: Ideal for mass production where speed and accuracy in workpiece changes are crucial.
• Efficient machine time utilization: Pneumatic vises increase work efficiency by eliminating long downtimes during workpiece changes.

Warranty and Service:

• We provide full warranty and post-warranty service for VMC-8P vises, ensuring long-term reliability and support.
• This vise model offers the best price/performance ratio for mass production with professional customer support and service.
