Pneumatic Vise VMC-5P

Pneumatic Machine Vice VMC-5P

The VMC-5P vice is a precise, robust vice with a massive construction, ideal for demanding industrial applications. Thanks to its quick and reliable clamping and subsequent release of the workpiece, the VMC-5P is an excellent choice for series production, where short cycle times are crucial. This vice significantly improves work efficiency by reducing non-productive times associated with part changeovers.

Key Features:

• Maximum jaw opening: 150 mm
• Jaw width: 130 mm
• Clamping force: 6000 kgf
• Weight: 38 kg
• Switching speed: 1.5 s

Construction and Materials:

The vice is made of high-quality ductile iron, ensuring long life and high resistance to mechanical wear. The base and jaws are induction hardened, providing excellent strength and protection against wear during intensive use. Special clamping system: When tightening the vice, the moving jaw is pressed towards the base, preventing the workpiece from lifting and ensuring stable clamping.

Included in the package:

• 2x leveling blocks (18 mm) for precise vice adjustment.
• 4x clamps for secure and reliable workpiece holding.
• 1x handle for easy and efficient vice operation.

Advantages:

• Ability to mount multiple vices on the machine table for increased productivity and efficiency in series clamping.
• High clamping speed: Ideal for series production, where speed and precision in part changeovers are important.
• Efficient machine time usage: Pneumatic vices increase work efficiency by eliminating long downtimes during part changeovers.

Warranty and Service:

We provide comprehensive warranty and post-warranty service for the VMC-5P vices, ensuring long-term reliability and support. This model offers the best price/performance ratio for series production, supported by professional customer service and support.
