MHV-160 MC Power Machine Vise

MHV-160 Hydraulic Machine Vise

The MHV-160 hydraulic machine vise is a robust and highly precise tool designed for demanding industrial applications. This vise offers excellent performance, reliability, and accuracy, making it ideal for machining and other precision operations.

Key Features:

• Accuracy: 0.02 mm / 100 mm
• Maximum jaw opening: 240 mm
• Jaw width: 160 mm
• Weight: 60 kg
• Clamping force: 5000 kgf

Construction and Materials:

• Made from high-quality ductile iron, ensuring long life and resistance to mechanical stress.
• Induction-hardened base and jaws for maximum strength and wear resistance.
• Special pressure system for the movable jaw: The movable jaw is pushed towards the base during tightening, preventing workpiece lift and ensuring stable and precise clamping.

Included in the Package:

• 2x leveling blocks (18 mm)
• 4x clamps
• 4x T-nuts with clamping screws (18/M16)
• 1x handle

Advantages:

• Multiple vises can be mounted on the machine table for increased productivity.
• Sturdy construction and high clamping force for professional and industrial use.

Warranty and Service:

We offer warranty and post-warranty service for the MHV-160 vise, ensuring long-term reliability and optimal performance.
